Plasma spraying tape (B828N)
Plasma spray tape It is a fiberglass cloth tape with adhesive on both sides. The product features high tensile strength, good temperature resistance, insulation, flame retardancy, and other properties. It is widely used for protection in plasma, supersonic, flame, vapor deposition, and sandblasting processes for special industrial products such as turbine blades and aerospace components.Storage and transportation conditions：The parent roll or the entire length of adhesive tape should be transported and stored in a vertical position. The cut adhesive tape should be stored in its original packaging at 20±5℃,Avoid direct sunlight under humidity conditions of 40~65%.shelf life：For optimal performance, please use this product within 6 months of its manufacture.Transparent PET high-temperature resistant tape (silicone)
Transparent PET high-temperature resistant tape Product description: This tape is made of soft polyester film as the substrate, with one side coated with high-performance silicone pressure-sensitive adhesive. It exhibits excellent high-temperature resistance, no residue, and solvent resistance! This product can be laminated with fluorine-based release film and cut to the width required by customers. The model number is followed by an FmodelT2535T2540T2550T3850T3855T3860T5060T5070T5080T50100T75100customizablesubstrate thickness25um25um25um38um38um38um50um50um50um50um75umcustomizabletotal thickness35um40um50um50um55um60um60um70um80um100um100umstickinessN/25mm5-76-87-106-88-108-105-77-109-1110-139-11tensile strength120120120130130130140140140140160Elongation at break5555556060606060606060Withstand Voltage/KV1.51.51.522233335heat-resistant℃/30min220220220220220220220220220220220Product Features:High temperature resistance, high adhesion, soft and conformable, and no residue left after removal.Application fields:Motor insulation, powder coating, ultra-high temperature baking paint, electroplating and other industries.Storage conditions and expiration date:The product should be stored at room temperature, within an environment with a temperature range of 20℃ to 80%RH. Good performance can be achieved if the product is used within 3 months after the production date.Notes:The above technical data are average values obtained through multiple tests conducted by our company using recognized and reliable testing methods. However, forTo ensure the correct selection and use of our company's products, please first carefully consider the intended purpose and conditions of use based on the intended recipientPlease fully understand and try it, or notify our company so that we can provide you with further explanations and services.Blue PET high-temperature resistant tape (silicone)
Blue PET high-temperature resistant tape (silicone) Product description: This tape is made of soft polyester film as the substrate, with one side coated with high-performance silicone pressure-sensitive adhesive. It exhibits excellent high-temperature resistance, no residue, and solvent resistance! This product can be laminated with fluorine-based release film and cut to the width required by customers. The model number is followed by an FmodelT2535T2540T2550T3850T3855T3860T5060T5070T5080T50100T75100customizablesubstrate thickness25um25um25um38um38um38um50um50um50um50um75umcustomizabletotal thickness35um40um50um50um55um60um60um70um80um100um100umstickinessN/25mm5-76-87-106-88-108-105-77-109-1110-139-11tensile strength120120120130130130140140140140160Elongation at break5555556060606060606060Withstand Voltage/KV1.51.51.522233335heat-resistant℃/30min220220220220220220220220220220220Product Features:High temperature resistance, high adhesion, soft and conformable, and no residue left after removal.Application fields:Motor insulation, powder coating, ultra-high temperature baking paint, electroplating and other industries.Storage conditions and expiration date:The product should be stored at room temperature, within an environment with a temperature range of 20℃ to 80%RH. Good performance can be achieved if the product is used within 3 months after the production date.Notes:The above technical data are average values obtained through multiple tests conducted by our company using recognized and reliable testing methods. However, forTo ensure the correct selection and use of our company's products, please first carefully consider the intended purpose and conditions of use based on the intended recipientPlease fully understand and try it, or notify our company so that we can provide you with further explanations and services.Red high-temperature resistant silicone adhesive tape for PET
Red PET high-temperature resistant tape Product description: This tape is made of soft polyester film as the substrate, with one side coated with high-performance silicone pressure-sensitive adhesive. It exhibits excellent high-temperature resistance, no residue, and solvent resistance! This product can be laminated with fluorine-based release film and cut to the width required by customers. The model number is followed by an FmodelT2535T2540T2550T3850T3855T3860T5060T5070T5080T50100T75100customizablesubstrate thickness25um25um25um38um38um38um50um50um50um50um75umcustomizabletotal thickness35um40um50um50um55um60um60um70um80um100um100umstickinessN/25mm5-76-87-106-88-108-105-77-109-1110-139-11tensile strength120120120130130130140140140140160Elongation at break5555556060606060606060Withstand Voltage/KV1.51.51.522233335heat-resistant℃/30min220220220220220220220220220220220Product Features:High temperature resistance, high adhesion, soft and conformable, and no residue left after removal.Application fields:Motor insulation, powder coating, ultra-high temperature baking paint, electroplating and other industries.Storage conditions and expiration date:The product should be stored at room temperature, within an environment with a temperature range of 20℃ to 80%RH. Good performance can be achieved if the product is used within 3 months after the production date.Notes:The above technical data are average values obtained through multiple tests conducted by our company using recognized and reliable testing methods. However, forTo ensure the correct selection and use of our company's products, please first carefully consider the intended purpose and conditions of use based on the intended recipientPlease fully understand and try it, or notify our company so that we can provide you with further explanations and services.Green PET high-temperature tape (silicone)
Green PET silicone tapeProduct description: This tape is made of soft polyester film as the substrate, with one side coated with high-performance silicone pressure-sensitive adhesive. It exhibits excellent high-temperature resistance, no residue, and solvent resistance! This product can be laminated with fluorine-based release film and cut to the width required by customers. The model number is followed by an FmodelT2535T2540T2550T3850T3855T3860T5060T5070T5080T50100T75100customizablesubstrate thickness25um25um25um38um38um38um50um50um50um50um75umtotal thickness35um40um50um50um55um60um60um70um80um100um100umstickinessN/25mm5-76-87-106-88-108-105-77-109-1110-139-11tensile strength120120120130130130140140140140160Elongation at break5555556060606060606060Withstand Voltage/KV1.51.51.522233335heat-resistant℃/30min220220220220220220220220220220220Product Features:High temperature resistance, high adhesion, soft and conformable, and no residue left after removal.Application fields:Motor insulation, powder coating, ultra-high temperature baking paint, electroplating and other industries.Storage conditions and expiration date:The product should be stored at room temperature, within an environment with a temperature range of 20℃ to 80%RH. Using the product within 3 months after the production date can ensure good performance.Notes:The above technical data are average values obtained through multiple tests conducted by our company using recognized and reliable testing methods. However, forTo ensure the correct selection and use of our company's products, please first carefully consider the intended purpose and conditions of use based on the intended recipientPlease fully understand and try it, or notify our company so that we can provide you with further explanations and services.Ceramic-backed tape, fire-resistant self-adhesive tape
Ceramic-backed tape, fire-resistant self-adhesive tapeMade from ceramicized silicone rubber and refractory reinforcing fibers, it is a high-strength flexible composite product with excellent fire resistance, high temperature resistance, and superior high-temperature insulation properties. It can withstand flame ablation up to 1000°C, preventing the spread of flames to other areas. It effectively isolates most chemical solvents and is specifically designed as a heat-resistant and electrical insulation protection material, enhancing the safety of battery packs in electric vehicles and other energy storage systems.constituteSubstrate: Ceramic silicone adhesive tapeAdhesive: Acrylic adhesivepurposeSuitable for PACK battery packs and high-voltage electrical connection structural components;Fields such as new energy vehicle battery module protection, electronics, aerospace, rail transit, chemical industry, and morefeature1. Good bonding performance, no warping2. Tear resistance, acid and alkali resistance, UV resistance3. Long service life, environmentally friendly and halogen-free4. Withstands voltage of over 15KV and temperature up to 1000℃,5. It ceramicizes instantly upon exposure to fire, forming a hard shell, achieving a flame retardant rating of FV-V0 unitmeasured valuetotal thicknessμm170~350Initial adhesion (rolling ball method)号/刚球≧9180 °peel strengthKG/25mm≧0.75retentionhrs/25MM≧72Operating temperature℃-15~1000Precautions1. Shelf life: Under the following storage conditions, the shelf life of this product is 6 months from the date of shipment.2. Please store in a cool and ventilated place: below 30°C, within 65%RH, and avoid direct sunlight.3. The surface to be pasted must be kept clean and free from dust, oil stains, and moisture to avoid affecting the pasting effect.4. If you have any questions regarding the product usage, please consult our company.Replacement for DACHSER 4174 paint color separation tape
TD4174 4104 4185 tapeDescription: It can perfectly replace models such as Dachser 4174, 4104, and 4185.Characteristics: Matte soft PVC film, coated with weather-resistant rubber adhesive.It has moderate viscosity, good tearability, excellent temperature resistance, and leaves no plies with RoHS 2002/95/EC.Physical properties:Thickness: 0.120±10% mmTensile strength: 1.8Kg/10mmColor: Earthy yellow/greenElongation: 150%Adhesion: 0.16Kg/10mmTemperature resistance: 170℃ for 1 hourBased on the above characteristics, these tapes are highly suitable for the following scenarios:• Automotive manufacturing: body painting, color segmentation, high-temperature masking in electrophoresis tank• Precision industrial spraying: coating protection for aerospace components and electronic equipment casings• High-temperature process scenarios: Protection for products that require baking or high-temperature curing.Note: 1. For any special requirements beyond the above specifications, please contact our salesperson.2. The data provided are average values (ASTM D 1000) and are for reference only. Users should confirm the applicability of the product.3. The test subject is a PS TC standard steel plate. The performance of the test subject made of other materials needs to be confirmed by the user.TD69 glass cloth tape
TD69 glass cloth tapeThis product is made by applying a specially formulated silicone adhesive to imported fiberglass cloth, featuring a texture and performance similar to that of 3M 69.Performance:1. For use between low temperature -70℃ and high temperature 260℃. 2. Resistant to ozone, oxygen, light, and weather aging, it exhibits excellent weather resistance and long service life. 3. It possesses high insulation performance.Primary use:1. Electrical insulation: Silicone rubber fabric has a high level of electrical insulation, capable of withstanding high voltage loads, and can be made into insulation cloth, sleeves, and other products. 2. Non-metallic compensator: Silicone rubber fabric can serve as a flexible connecting device for pipelines, addressing the damage caused by thermal expansion and contraction. With high temperature resistance, corrosion resistance, anti-aging properties, and good elasticity and flexibility, silicone rubber fabric can be widely applied in the fields of petroleum, chemical industry, cement, energy, and more. 3. In terms of corrosion prevention: Silicone rubber coated with fiberglass cloth can serve as an internal and external corrosion-resistant layer for pipelines and storage tanks. It boasts excellent corrosion resistance and high strength, making it an ideal corrosion-resistant material. 4. Other fields: Silicone rubber-coated fiberglass membrane structural materials can be applied in fields such as building sealing materials, high-temperature anti-corrosion conveyor belts, and packaging materials.Fire-resistant ceramicized silicone tape
Ceramic silicone tape Made from ceramicized silicone rubber and refractory reinforcing fibers, it is a high-strength flexible composite product with excellent fire resistance, high temperature resistance, and superior high-temperature insulation properties. It can withstand flame ablation at 1000°C, preventing the spread of flames to other areas. It effectively isolates most chemical solvents and is specifically designed as a heat-resistant protective and electrical insulation material, enhancing the safety of battery packs in electric vehicles and other energy storage systems.constituteBase material: Ceramic silicone clothAdhesive: Acrylic adhesivepurposeSuitable for PACK battery packs and high-voltage electrical connection structural components;New energy vehicle battery module protection, electronics, aerospace, rail transit, chemical and other fields, etcfeature1. Good bonding performance, no warping2. Tear resistance, acid and alkali resistance, UV resistance3. Long service life, environmentally friendly and halogen-free4. Withstands voltage of over 15KV and temperature up to 1000℃,5. Ceramicization occurs instantly upon exposure to fire, forming a hard shell with a flame retardant rating of FV-V0feature unitmeasured valuetotal thicknessμm170~350Initial adhesion (rolling ball method)号/刚球≧9180 °peel strengthKG/25mm≧0.75retentionhrs/25MM≧72Operating temperature℃-15~1000Precautions1. Shelf life: Under the following storage conditions, the shelf life of this product is 6 months from the date of shipment.2. Please store in a cool and ventilated place: below 30°C, within 65%RH, and avoid direct sunlight.3. The surface to be adhered must be kept clean and free from dust, oil stains, and moisture to avoid affecting the adhesion effect.4. If you have any questions regarding the product usage, please consult our company.Teflon tape (PTFE tape)
Teflon tapeTeflon tape (PTFE tape) is a high-temperature resistant tape made of glass fiber as the base cloth, coated with polytetrafluoroethylene (PTFE) lotion and compounded with silicone adhesive.Its core characteristics include high temperature resistance (-196℃ to 300℃), anti-adhesion, chemical corrosion resistance, high insulation, and high strength, making it reusable in extreme environments.structure1. Teflon cloth2. Silicone glueperformanceProduct NameFUHAOF013F018customizablesubstrate thickness um80130total thickness um130180Basic weight g150initial tackN/5CMInsulation breakdown voltageKVtemperature resistance℃Product radial strengthN/5CMProduct weft strengthN/5CM
